Продавам качествен усилвател DENON PMA 770 → Обява 16477618

Усилвателя е много добро състояние много е подходящ за грмофон заради минималните THD 0.002% or less (at the time of 1kHz and 8V output) изкривявания ето и техническите му характеристики

Form Integrated Amplifier

Circuit system Unreturned [ of 0dB ] power amplifier system

Output power

(both channel drive, a sine wave continuation output, 20Hz - 20kHz) 140W+140W (4ohms)

100W+100W (8ohms)

Input sensitivity/impedance 150mV/47kohm

THD (20Hz - 20kHz, Output-power-3dB o'clock) 0.005% or less

Cross modulation distortion

(at the time of a 60Hz:7kHz=4:1 and Output-power equivalent amplitude output) 0.002% or less

Output bandwidth (IHF, both ch(es) drive, THD 0.035%) 5Hz - 100kHz

Frequency response (at the time of 1W output) 1Hz-250kHz+0 -3 dB

Output load impedance (1kHz) 0.08ohm

Output terminal Speaker AorB: 4ohms - 16ohms

Speaker A+B: 8ohm-16ohm

Headphone: 390mW/eight ohms

Rec out)>

Circuit system The super equalizer system by a direct direct-current servo

Input sensitivity/impedance Phono MM: 2.5mV/47kohm

Phono MC: 0.125mV/100 ohms

Tuner, Aux, Tape:150mV/47kohm

The maximum except take-off/Output power 10V/150mV

RIAA deflection (MC/MM) 20Hz-100kHz±0.2dB

THD 0.002% or less (at the time of 1kHz and 8V output)

Signal to noise ratio (IHF-A, input short circuit) Phono MM:90dB

Phono MC:73dB

Tuner, Aux, Tape: 110dB (at the time of a 150mV input)

Tone control Bass: ±8dB (100Hz)

Treble: ±8dB (10kHz)

Subsonic Filter 18Hz, 6 dB/oct

Loudness characteristic Low-pass: +7dB (100Hz)

High region: +6dB (10kHz)

Power source AC100V, 50Hz/60Hz

Power consumption (Electrical Appliance and Material Control Law) 290W

Dimensions Width 434x height 132x depth of 407mm

Weight 12kg

ето и линк с цената му като нов
