5в1 Hikvision HiWatch HWD-6116MH-G2 DVR 16 Канала 4MPlite(HDTVI/AHD/CVI/CVBS) + 8xIP H.265Pro+ Аудио → Обява 29746942

5в1 Мултихибриден Видео Рекордер с поддържка на 16 Канала Камери от вида HDTVI/AHD/CVI/CVBS + 8 броя IP Камери или 24 броя IP Камери

Брой канали: 16 BNC interface (1.0 Vp-p, 75 Ohm) с поддръжка на "Coaxitron" връзка

Видео компресия: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264

Аудио компресия: G.711u

HDMI: 1-ch, 4K (3840 x 2160)/30Hz, 2K (2560 x 1440)/60Hz, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz; VGA: 1-ch, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz

Аудио изход: 1-ch, RCA (Linear, 1 KOhm); Dual stream - Support

Входове: Turbo HD input; AHD input; HDCVI input; CVBS input; Audio input (1-ch, RCA); IP video input - 8-ch (up to 24-ch), Up to 6 MP resolution

Мрежови протоколи: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS; Remote connections 128

Мрежови интерфейс: 1, RJ45 10M/100M/1000M self-adaptive Ethernet interface

Поддържа хард диск: 1 SATA interface (до 10 TB капацитет)

USB портове: 2 x USB 2.0

Ползва захранване: 12 VDC (включено в комплекта)

Консумация (без HDD): ≤ 20 W

Работна температура: -10°C to +55°C

Влажност на въздъха: 10% до 90%

Размери: 26 × 22.2 × 4.5 см

Тегло: ≤ 1.2 kg

-Simultaneous HDMI output at up to 4K (3840×2160) resolution/VGA (1920×1080) resolution

-16-ch Analog Video input

Video/Audio input

Video compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264

Analog video input: 16-ch

HDTVI input: 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30

Note: The 3 MP signal input is only available for the first 4 channels of HWD-6116MH-G2.

AHD input: 4 MP, 1080p25, 1080p30, 720p25, 720p30

HDCVI input: 4 MP, 1080p25, 1080p30, 720p25, 720p30

CVBS input: Support

IP video input: 8-ch (up to 24-ch)

Audio compression: G.711u

Audio input: 1-ch, RCA (2.0 Vp-p, 1 KΩ)

Video/Audio output

HDMI/VGA output HDMI:

1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

VGA: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

Encoding resolution:

When 4 MP Lite mode not enabled: 4 MP/4 MP Lite/3 MP/1080p/720p/WD1/4CIF/VGA/CIF;

When 4 MP Lite mode enabled: 4 MP lite/3 MP/1080p lite/720p lite/WD1/4CIF/VGA/CIF

When 1080p Lite mode not enabled: 4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF;

When 1080p Lite mode enabled: 4 MP/3 MP/1080p lite/720p lite/WD1/4CIF/VGA/CIF

Main stream Frame rate:

For 3 MP stream access: 3 MP@15fps; For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

When 4 MP Lite mode not enable: For 4 MP stream access: 4 MP@8fps; 4 MP lite/1080p/720p/WD1/4CIF/VGA/CIF@15fps (N)

When 4MP Lite mode enabled: For 4 MP stream access: 4 MP lite@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

When 1080p Lite mode not enabled: For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

When 1080p Lite mode enabled: For 1080p stream access:1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

Sub-stream Frame Rate WD1/4CIF/2CIF@12fps; CIF/QVGA/QCIF@25fps (P)/30fps (N)

Video bit rate: 32 Kbps to 4 Mbps

Audio output: 1-ch, RCA (Linear, 1 KΩ)

Audio bit rate: 64 Kbps

Dual stream: Support

Stream type: Video, Video & Audio

Synchronous playback: 16-ch

Remote connections: 128

Network protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS

Hard disk SATA Interface: 1 SATA interface

Hard Disk Capacity: Up to 10 TB capacity for each disk

Two-way audio input: 1-ch, RCA (2.0 Vp-p, 1 KΩ)

Network interface: 1, RJ45 10M/100M/1000M self-adaptive Ethernet interface

USB interface: Rear panel: 2 × USB 2.0
