KVR400X64C3A/512 → Обява 42222662

KVR400X64C3A/512

512MB 64M x 64-Bit DDR400

CL3 184-Pin DIMM

64M x


64-bit (512MB)

DDR400


CL3 SDRAM (Synchronous DRAM) memory module.

The


components on this module include sixteen 32M x 8-bit

(8M x


8-bit x 4 Bank) DDR400 SDRAM in TSOP packages. This

184-pin


DIMM uses gold contact fingers and requires +2.6V.

SPECIFICATIONS

Clock


Cycle Time (tCK) 5ns (min.) / 10ns (max.)

Row Cycle


Time (tRC) 55ns (min.)

Refresh


Row Cycle Time (tRFC) 70ns (min.)

Row


Active Time (tRAS) 40ns (min.) / 70,000ns (max.)

Single


Power Supply of +2.6V (+/- .1V)

Power


3.224 W (operating)

UL Rating


94 V - 0
