Power supply
Monofazic, 220 – 240, 50Hz
Nominal cooling capacity (Min~Max)
kW
2.5(0.9~3.1)
Nominal heating capacity (Min~Max)
kW
2.8(1.0~4.1)
Energy consumption
Cooling/Heating
kW
0.710 / 0.690
EEA/COP
Cooling/Heating
3.52/4.05
UI
Cooling/Heating
dB(A)
57 / 57
UI
Cooling (Hi/Me/Lo/Ulo)
45 / 34 / 23
Heating (Hi/Me/Lo/Ulo)
43 / 34 / 26
Air flow
UI
Cooling (Hi/Me/Lo/Ulo)
10.0 / 7.3 / 4.2
Heating (Hi/Me/Lo/Ulo)
9.5 / 7.3 / 5.2
EU
Cooling/Heating
23.7 / 19.7
External dimensions
UI
Height / Width / Depth
mm
267 x 783 x 210
net weight
UI / UE
kg
7.0 / 26.5
Refrigerant
Tip/GWP
R32 / 675
Refrigerant
Loading
kg/TCO2Eq
0.550 / 0.371
Refrigerant pipe dimensions
Liquid/Gas
mm/⌀
6.35(1/4″) / 9.52(3/8″)
Refrigerant pipe length (one direction)
m
Max. 15
Supported level difference
Outdoor unit is higher/lower
m
Max. 10 / Max. 10
Operating range
– outdoor temperature
Cooling
°C
-15~46
Energy Class (Cooling/Heating)
A++/A+
PURPOSE (Temperate climate)
4.10
Pdesign (cooling/heating (@-10°C))
kW
2.50/2.80
Annual electricity consumption (cooling/heating)
kWh/a
129/957
Heating mode performance
Temperate climate
