Ресивера е много запазен: 9 от10.Вече рядкост в това състояние. За повече информация на посочения телефон.
FM Stereo Frequency Range: 88 -108 MHz
Usable Sensitivity (IHF): 1,7 µV
Harmonic Distortion Factor:
Mono : 0,15% (400 Hz)
Stereo : 0,25% (400 Hz)
Signal-to-Noise Ratio: 74 dB
Selectivity (IHF): 80 dB
Image Rejection Ratio: 85 dB
IF Rejection Ratio: 100 dB
Capture Ratio: 1 dB
AM Suppression Ratio: 55 dB
FM Stereo Separation: 45 dB (1kHz)
AM Frequency Range: 530 - 1605 kHz
Usable Sensitivity: 300 µV/m (S/N 20 dB, 20 µV (IHF)
Image Rejection Ratio: 50 dB
IF rejection Ratio: 50 dB
Signal-to-Noise Ratio: 50 dB
Selectivity (IHF): 35 dB
Audio Section
Music Power (IHF):
80 W/ch + 80 W/ch (8 Ω, 1 kHz, 0,5% THD)
70 W/ch + 70 W/ch (4 Ω, 1 kHz, 0,5% THD)
RMS Power Output (both channel driven): 50 watts per channel, min. RMS, at 8 Ω from 20 - 20,000 Hz, with no mor than 0,5% THD
60 W/ch + 60 W/ch (8 Ω, 1 kHz, 0,5% THD)
70 W/ch + 70 W/ch (4 Ω, 1 kHz, 0,5% THD)
Frequency Characteristics: 10 Hz - 30 kHz (±1 dB)
Harmonic Distortion:
At rated output : 0,5%
At ½ rated output : 0,05%
Power bandwidth: 10 - 40,000 Hz
Tone Control:
Bass : ±10 dB at 100 Hz
Treble : ±10 dB at 10 kH
