Absolute Maximum AC Current Measurement
1000A ac
Absolute Maximum DC Current Measurement
1000A dc
Absolute Maximum AC Voltage Measurement
1000V ac
Absolute Maximum DC Voltage Measurement
1000V dc
Absolute Maximum Resistance Measurement
100kΩ
AC Current Measurement Resolution
100mA
DC Current Measurement Resolution
100mA
Best DC Current Accuracy
±(1.5% rdg + 5dgts)
Clamp Meter Type
Power Clamp Meter
Best AC Current Accuracy
±(1.5% rdg + 5dgts)
Best AC Voltage Accuracy
±(1% rdg + 5dgts)
Functions Measured
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Harmonics, Power, Power Factor, Resistance, Temperature, Total Harmonic Distortion
Best DC Voltage Accuracy
±(0.7% rdg + 2dgts)
AC Voltage Measurement Resolution
100mV
Maximum Conductor Size
42mm
Safety Category Level
CAT III, CAT IV
Minimum Operating Temperature
0°C
Dimensions
87.5 x 50.5 x 257mm
Resistance Measurement Resolution
100mΩ
Non-Contact Voltage Detector
Yes
DC Voltage Measurement Resolution
100mV
Temperature Measurement Resolution
0.1°C
Maximum Operating Temperature
+50°C
Best Resistance Measurement Accuracy
±1 % + 3 Digits
Safety Category
CAT III 1000 V, CAT IV 600V
Absolute Maximum Temperature Measurement
+1000°C
Battery Type
9 V Alkaline (NEDA 1604 or IEC 6F22)
Safety Category Voltage
600 V, 1000V
Best Temperature Measurement Accuracy
±1 % + 1 °C
