Absolute Maximum AC Current Measurement
400A ac
Absolute Maximum AC Voltage Measurement
600V ac
Absolute Maximum DC Voltage Measurement
600V dc
Absolute Maximum Resistance Measurement
20MΩ
AC Current Measurement Resolution
0.01A ac
Clamp Meter Type
AC Current Clamp Meter
Best AC Current Accuracy
±2.5% ± 5 Digits
Best AC Voltage Accuracy
±1.5% ± 10 Digits
Best DC Voltage Accuracy
±1.5% ± 2 Digits
Functions Measured
AC Current, AC Voltage, Continuity, DC Voltage, Diode Test, Resistance, Temperature
Safety Category Voltage
600V
Non-Contact Voltage Detector
Yes
Minimum Operating Temperature
+5°C
AC Voltage Measurement Resolution
0.1mV ac
Safety Category Level
CAT III
Maximum Operating Temperature
+40°C
Absolute Maximum Temperature Measurement
+1400 °F, +760°C
Safety Category
CAT III 600 V
Best Resistance Measurement Accuracy
±1% ± 4 Digits
Temperature Measurement Resolution
1 °C, 1 °F
Best Temperature Measurement Accuracy
±3% ± 5 Digits
DC Voltage Measurement Resolution
0.1mV dc
Resistance Measurement Resolution
100mΩ
Dimensions
82 x 40 x 230mm
