Audiolab Omnia AMP, CD, Streamer, DAC, Bluetooth, USB
Нов. Закупен от Англия от Peter Tyson. Отворена кутия, тестван - всичко е ОК.
Лично предаване за София.
Следват характеристики от сайта на Audiolab.
General Description Integrated Amplifier:
2x50W (8ohm) / 2x75W (4ohm) Class AB
ES9038Q2M 32-bit DAC
4.3" (80x48mm) large size full view IPS LCD
Built in certified hardware MQA Full decoder (PC USB, Coax/Optical)
CD playback compatible with CD, CD-R, CD-RW discs
USB memory device support (MP3/WMA/AAC/WAV)
DTS Play-Fi technology (IEEE 802.11 a/b/g/n/ac)
Streaming service support includes Amazon Music, Spotify, TIDAL, KKBox, SiriusXM, Napster, Internet Radio, Deezer, iHeartRadio, PANDORA, Qobuz, QQmusic and more
Multi-room / multi speaker group support
Bluetooth 5.0 (aptX/aptX LL) streaming
Low Noise Moving Magnet Phono stage
Dedicated Current-Feedback Headphone AMP
Integrated / PRE-POWER / PRE only Modes
Android / iOS / Kindle Fire / Windows PC Control Support
USB firmware upgrade input
Inputs:
3 x Analogue, 1 x Phono (MM) , 1 x Power Amplifier, 2 x SPDIF (Coax),
2 x SPDIF (Optical), 1 x DTS Play-Fi Streaming, 1xPC USB(USB B),
1xUSB HDD(USB A), 1 x Bluetooth(aptX/aptX LL), 1 x 12V Trigger
Outputs: 1 x PRE Amplifier, 1 x Stereo Speaker, 1 x Headphone, 1 x 12V Trigger
Sampling Frequency:
Optical / Coaxial:44.1kHz ---192kHz
PC USB: 44.1kHz - 768kHz (PCM) / DSD64, DSD128, DSD256, DSD512
Preamplifier Section:
Gain:
+8dB (Line)
+47dB (Phono MM)
Input Sensitivity:
720mV (Line, Volume = 0dB)
3.1mV (Phone MM, Volume=0dB)
Input Impedance:
10K (Line)
47K // 100pF (Phono MM)
Total Harmonic Distortion (THD): < 0.0004% (1KHz at 2V, Volume = 0dB)
Frequency Response: 20Hz-20kHz (+/-0.1dB)
Output Voltage: 2.3V max. (Volume = 0dB)
Output Impedance: 100 ohm
Signal-to-Noise Ratio:
>110dB (Line,A-weighted)
76dB (Phono MM,A-weighted)
DAC:
D to A Converte: ES9038Q2M
Total Harmonic Distortion (THD): < 0.0006% (1KHz at 0dBFS)
Output level (0dBFS, 1KHz): 2.1Vrms
Max. Sampling Frequency:
Optical, Coaxial: 192KHz
Ethernet,Wi-Fi: 192KHz
USB A:48kHz
PC USB: PCM768kHz, DSD512
Signal-to-noise Ratio (S/N): 114dB (A-weighted)
Power Amplifier Section:
Gain: +29dB
Rated Power Output:
2 x 50W (8 ohm, THD < 1%)
2 x 75W (4 ohm, THD < 1%)
Frequency Response: 20Hz-20kHz (+/-0.3dB)
Total Harmonic Distortion (THD): < 0.003% (1kHz at 40W / 8ohm)
Input Sensitivity: 720mV
Signal-to-Noise Ratio (S/N): 110dB (A - weighted)
Max. Output Current: 9A
Headphone Amplifier:
Total Harmonic Distortion (THD): < 0.01% (1kHz, 50mW )
Output Impedance: 10ohm
Load impedance: 20-600 ohm
General:
Standby Power Consumption: < 0.5W
Net Weight: 9.1kg
Gross Weight: 11kg
Dimensions (mm) (W x H x D): 440 x156 x 327
Carton Size (mm) (W x H x D): 540 x 412 x 210
Finish: Black
Power Requirements (depending on region):
220-240V ~ 50/ 60Hz
100-120V ~ 50/ 60Hz
Standard Accessories: Power Cord, Remote Control, User Manual, Antennas.
